EZ80001100 Installation

OVERVIEW

The EZ80001100 is designed to split a single Cat-5/6 type cable into 2 separate circuits for use with TCP/IP type devices, such as Personal Computers, Servers, Printers, Network Cameras, Network Telephones, Network Storage Devices, Smart TV’s, Game Consoles, etc.

Each EZ80001100 has 1 plug and 2 jacks, with one jack’s cord slightly shorter than the other. The shorter cord is circuit #1 and the longer cord is circuit #2.

You will need 1 EZ80001100 wiring harness at each end.

VIDEO TUTORIAL
Sometimes, a picture is worth a thousand words. We know this and so we have created a video for each of our cords. If you would like to see how the EZ80001100 is used, simple click here:
http://ezcords.com/ez80001100-video/

INSTALLATION

1. In the Equipment Room, plug the 8-pin, RJ45 plug into the port of the Main Patch Panel that you want to split into separate circuits.
2. Insert an Industry Standard, 8-pin patch cord of a length appropriate for your application into Jack #1 and then plug the other end of that patch cord into the Ethernet Port on the data switch or router/firewall that you are using.
3. Repeat Step-2 for circuit #2, using another port on either the data switch or router.
4. Locate the wall jack at the far end of the cable run that the EZ80001100 is plugged into. Plug another EZ80001100 into that wall outlet.
5. Plug the first TCP/IP type device into Jack #1 (the shorter cord).
6. Plug the second TCP/IP type device into Jack #2 (the longer cord).

TESTING

If you followed the steps as outlined above, both devices will work unless:

• One or both of the data switch ports or router/firewall ports are bad or configured improperly;
• You are plugged into the wrong port of the Main Patch Panel;
• You are plugged into the wrong RJ45 wall jack outlet;
• One or both of the end devices are bad.

EZCORDS are passive devices, meaning that they have no electronics that could go bad.
